What Are the Parts Of SCBA?

The main parts of an SCBA are one or two compressed air cylinders, a harness that carries them on the wearer's back, a pressure-reducing valve and demand valve, and a full facemask held at positive pressure.

A Self-Contained Breathing Apparatus, also known as SCBA, is essential protective gear that's worn by paramedics, firefighters, and individuals working on ships and oil rigs. As the name suggests, the breathing device has all the fundamental gear fitted into it that will permit the rescue professionals to carry out their work without any interruption and with the utmost safety.

There are Two Major Types of SCBA

These are in use nowadays – the Open Circuit SCBA and also the Closed Circuit SCBA. The distinction between the two is that the latter one is utilised for rescue operations that tend to be exceptionally long. In this sort of SCBA, the air is continuously re-processed or recycled so that the wearer of the SCBA gets a nonstop supply of air. In the former variety, air is compressed to fit into the air cylinders.

These SCBA are utilised for shorter rescue operations. The SCBA utilised onboard ship is of the open circuit sort for the most part. In this, the exhaled breath is released into the air, whereas the discharge from the cylinder is made available for inhalation.

The Gear Comprises of:

• One or two cylinders containing air under pressure.
• A harness to mount the cylinders on the back of the individual.
• A respiratory system which includes a means of reducing the pressure of air from the cylinder and providing the wearer with air on demand.
• A facemask is connected to a demand valve that maintains a positive pressure inside the mask at all times.

Air Cylinders

The first and foremost presence within the air-breathing device is that of Air Cylinders. The closed-circuit SCBA is known as the re-breather, because it reuses the air (as mentioned above). Air cylinders, on the other hand, are filled with air in a compressed form that enables a rescue professional to go into regions that are filled with smoke and fire and free the trapped individuals effectively.

The parts of SCBA within the breathing device ought to be consistently checked after the rescue operation is carried out so that they don't end up being emptied the next time a rescue operation has to be carried out. Each set must also have spare air cylinders (normally two), so that the apparatus can be used again.

Protective Hood

The second-most important presence is that of a Protective Hood. Such hoods are designed in a way that they cover all the parts of the face and also have an eye-covering (visor) that enables an individual to see and also permits the desired oxygen to pass continuously. They, too, have tubes attached to ensure that the air passes continuously.

Portable Carrying Bag

The portable carrying bag is also important equipment for the breathing device. It can be filled with air cylinders, hoods, and any other protective equipment that would be fundamental to the rescue operations. The bag is made of a fabric that is resistant to damage and hence can be effectively used in any sort of emergency situation.

Portable Pulling Pack

The final breathing device gear is the Portable Pulling Pack. The biggest difference between this sort of carrying sack and the one mentioned already is that in this sack, the extra weight of the essential items can be carried. It is utilized for the purpose of getting the parts of SCBA equipment from the central command of the rescue professionals to the place where the incident has actually happened.

It is only at the accident location that the gear is transferred from this bigger pack to the Portable Carrying Bag.

A breathing device has changed the complete rescue operation process, making it easier and safer. More lives can be saved because of the compactness of the parts of SCBA. It, hence, becomes imperative and significant to recognize and appreciate the worth of the SCBA in today's times.

The Arrangement of the Full Device is as Follows:

• The cylinders contain at least 1200 liters of compressed air at 200-atmosphere pressure. A 1200 liter supply gives the wearer around 30 minutes of air supply for full utilisation or around 20 minutes for working conditions (a person breathes more heavily while working, so more air is used, which is why the time is shorter)
• The reducing valve decreases the cylinder pressure to a medium pressure of about 7 bar, which is further decreased by the demand valve which is connected to the mask
• The demand valve is the one that supplies the air to the wearer when breathing in
• The exhalation valve discharges the air from the facemask
• When the air left inside the device will last about 10 minutes (usually 55 bar +/-5 bar pressure), a warning whistle is sounded continuously till the cylinder gets emptied. The start of this whistle is a signal for the wearer to move out of the space he's in to fight fire or whatever reason it is utilized for.

Further Instructions

• The face mask is made of soft moulded natural rubber and five flexible head straps and a nylon cord or neck strap. It includes a foam-filled or air pad seal and a full vision visor. For correct positioning of the mask, the straps ought to be tightened in the order where the first two upper straps then the center pair and finally the lower pair are tightened. Care ought to be taken to not over-tighten them causing discomfort to the wearer. The mask is made of rubber and plastic with a shatterproof visor. It has an exhalation port with a speech diaphragm and a nose guard
• The wearer ought to have a great, clear field of vision through the visor.
• A gauge is provided, clipped or attached to the harness that carries the cylinder and it monitors the pressure inside the cylinder. It is positioned to be visible to the wearer.
• Spare cylinders must be provided for each set of breathing device and a small air compressor provided onboard to refill the cylinders with compressed air.
• If the facemask is removed in a harmful atmosphere, the wearer ought to hold his breath and position the mask accurately. Any intake of such poisonous air can be highly unsafe.

Approximate Consumption by a Person is as follows:

We subtract ten as 10 minutes is when the alarm begins ringing, and it is a safety margin that must be taken into consideration. So a 1200 litre cylinder will last for 1200/40 = 30 minutes minus the 10 = 20 minutes. Anxiety and excitement can cause an increased demand for oxygen and a proportionate increase in breathing rate.

Assembly Instructions

Open the cylinder support by squeezing the two sides of the support lever and open the cylinder strap. Line up the cylinder valve with the reducer valve hand wheel and turn the handwheel clockwise until hand tight. Hook the cylinder strap over the cylinder and pull down the operating lever onto the pressure spring to be clipped.

To connect demand valve assembly to facemask- line up assembly with the red bypass valve handle upwards with the centreline of facemask and turn assembly clockwise through 90 degrees until it clicks into place

Donning Instructions

• Hang the facemask from the neck by the neck strap.
• Lift the cylinder with the cylinder valve on top and backplate facing the wearer raise it over the head, and also position your hands to slide the shoulder straps onto the shoulders. Secure the waist belt and also tighten the shoulder straps.
• Alternatively, slide arms through shoulder straps and put the backplate on the back with the cylinder valve down. At that point, tighten the shoulder straps and also secure the waist belt.
• Open the cylinder valve by turning the handwheel gradually counterclockwise.
• Check the pressure on the gauge.
• Open all facemask straps completely. Hold your breath, put your chin into the facemask, and pull the head harness and also straps over the head.
• Ensure mask is accurately put on face with the nose guard on the nose and after that tighten upper straps first, and after that lower ones. Both side straps must be tightened together.
• Start to breathe deeply, which will activate positive pressure, and after that, breathe slowly.

Pre Use Checks

• Close the cylinder valve.
• Breathe normally to vent the system.
• Amid venting, watch gauge- whistle alarm ought to sound at a preset pressure of 55 bar +/-5 bar.
• When the gauge shows zero, hold your breath. The facepiece ought to hold onto the face, indicating a positive seal.
• Open the cylinder valve gradually but completely to pressurize the system.
• Breathe in and hold your breath. There ought to be no audible leak.
• Continue breathing. Exhaled air ought to effectively flow out of the exhalation valve.
• Press the middle of the rubber cover on the demand valve, check the supplementary supply.

During Use

• Check the display regularly.
• If the whistle sounds, move to a safe place with enough air.
• Remove the device only in a safe place.

After Use

• Press the reset lever on the demand valve to stop the air flow.
• Press and also hold the button to remove the demand valve.
• Insert your finger behind the neck strap and also push the buckle forward. Pull the mask forward, upwards over your head and back.
• Close the cylinder valve.
• Open the waist belt. If the shoulder straps become loose, also remove the equipment.

Periodic Inspection and Maintenance

The SCBA set must be inspected and also maintained regularly to ensure it remains functional at all times. Check the facemask straps and other rubber parts for wear. Wipe the mask with a mild disinfectant and a rinse under running water. Always wipe dry. Always perform a pre-use inspection after any maintenance.

Alarm Test

Open the cylinder valve.

• Pressurize the line to 200 bar.
• The pressure gauge shows 200 bar pressure.
• Close the cylinder valve.
• Check that the pressure does not drop by 10 bar within 1 minute.
• Open the demand valve, and also the pressure in the high-pressure line will start to drop.
• When the pressure is 50-60 bar, an alarm will sound, indicating that only 10 minutes are left to escape.

SCBA is a critical piece of equipment whose maintenance should be a top priority. Whether it is firefighting or confined space entry, the SCBA will help you in such situations. A thorough visual inspection should be performed on these devices every month. All valves, seals, and also speaker membranes should be inspected annually. The exhalation disc should be replaced every two years, and also the entire device should undergo a general overhaul every five years.
